MATHS
The MATHS music synthesizer module is an analog computer designed for musical purposes. Amongst other things, it will allow you to:

specifications
- Width: 20hp
- Max Depth
(incl. power cable): 32mm - Power:
60mA@ +12V
50mA @ -12V - manual:
- MATHSmanual2013.pdf
- MATHSmanual2013-japanese.pdf
- maths_manual-spanish.pdf
- MSRP: $290
- Where to buy
features
-
Generate a variety of linear, logarithmic, or exponential triggered or continuous functions
-
Integrate an incoming signal
-
With no signal applied, generate a variety of linear, logarithmic, or exponential functions
-
Add, subtract and OR up to 4 signals
-
Generate analog signals from digital information (Gate / Clock)
-
Generate digital information (Gate / Clock) from analog signals
-
Delay digital (Gate / Clock) information
-
If the above list reads like science rather than music, here is the translation:
Voltage Controlled Envelope or LFO as slow as 25 minutes and as fast as 1khz -
Apply Lag, Slew or Portamento to control voltages
-
Change the depth of modulation and modulate backwards!
-
Combine up to 4 control signals to create more complex modulations
-
Musical Events such as Ramping up or Down in Tempo, on command
-
Initiating Musical events upon sensing motion in the system
-
Musical note division and / or Flam
-
Perfect for modulating the DPO and just about anything else
- Page for Classic version of MATHS
